IRM-30-12ST
MEANWELL
1
Available Ship on today
AC-DC Single output Encapsulated power supply, Screw terminal, Input 85-264VAC, Output 12VDC / 2.5A, Compact size
PM,NFM,IRM > IRM
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | IRM-30-12ST |
---|---|
Long Description | Switching Power supply for Printed Circuit, connection by screw. Range of Universal Input85-264vac47-440Hz. Output voltage12vdc. Output intensity2,5 A.Range of output current 0-2,5 a according To demand load. Power:30W. Efficiency typical:88%. Consumption without load <0,1 W. Input class II without grounding. Operating temperature range of caseTcfrom-30up+70ºC. Dimensions (Length x Width x Height) [mm]:91 x 39.5 x 28.5. 3 years of warranty. Manufacturer: MEAN WELL. Version ST series IRM are to connect using terminal screws. This source is a class II non-grounded with double reinforced insulation. Has a minimum consumption without load which allows you to meet the requisitivos of ecological design with a small consumption in stand-by. It is CE certified and UL listed as power equipment limited "LPS". It has protection against over loads, short circuits and over-voltage output. Complies with EN55022 Class B without the need for additional components, although you should always verify the final design of the plate. |
Country of Origin | China |
Manufacturer | MEAN WELL |
Product type | Power supply AC/DC |
Format | For Printed Circuit |
Applications | Industrial, Telecommunications |
Series | IRM-30-xxST |
Warranty (Years) | 3,00 |
Height (mm) | 28.50 |
Width (mm) | 39.50 |
Long/Background | 91.00 |
Type of Entry CA | Single-phase |
AC input Min | 85,00 |
AC input Max | 264,00 |
Input frequency | 50 Hz, 60 Hz, 440 Hz |
Input connector | Screw-Type |
Output voltage | 12,00 |
Power (W) | 30,00 |
Peak Power (W) | Thirty |
Output connector | Screw-Type |
Isolation (V) | 3.000,00 |
Approvals | CE, UL |
