BPT14 nVent HOFFMAN Vortex thermostat kit 1/4 BPT14
BPT14
ELDON
Vortex thermostat kit 1/4 BPT14
Kit thermostat Vortex 1/4, BP/HT, 4x08, 4x15
The thermostat limits the flow of compressed air, in order for it to be used in situations when cooling is really needed. This saves compressed air, which reduces the operating costs.
Cabinet enclosures > Thermostat (switchgear cabinet)
General Accessories
* Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
More info
▲Technical data
Description: | Brass solenoid valve and thermostat that limit the flow of compressed air to only when cooling is needed. The thermostat is factory set at 35 °C, but adjustable to any other temperature. The thermostat mounts in a 22 mm diameter hole, and it may be mounted through the enclosure wall or on a bracket inside the enclosure. The thermostatically controlled vortex cooler saves compressed air, and it is recommended where heat load fluctuates and continual purge is not required. |
Voltage: | 240 V and 50 Hz. Other voltages on request. |
Delivery: | Thermostat with mounting bracket, and solenoid valve. |
Features
Feature: | Thermostat kit for vortex cooler to be connected to the vortex cooler. |
Advantage: | The thermostat controls the temperature inside the enclosure by opening and closing a solenoid valve allowing compressed air through to the vortex cooler. |
Benefit: | The compressed air is used efficiently as it is only supplied to the vortex cooler when the internal temperature is over what the thermostat kit is set to. This is particular important when mounting a vortex cooler due to the high operating costs to compress air. |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| BPT14 BPT14 EN_BPT14.pdf | 140 Kbytes |
 |
