DABP081606GE
ELDON
1
Available Ship on today
Terminal box, 80x160x56 DABP081606GE
Box for terminals, 80x160x56, without PW, ABS, IP66
The ABS terminal box range, DABP, with a IP 66, 67 protection degree, is available off the shelf in many different sizes. The DABP range is well suited for demanding environments, since water and dust are prevented from entering the terminal box, thus eliminating the risk for component failure, and with that unnecessary downtime.
Distribution boards > Empty cabinet
Terminal Boxes
* Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Description: | ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance. |
Material: | ABS. Transparent cover: polycarbonate. |
Gasket: | Polyurethane gasket integrated in the box cover. |
Temperature resistance: | -40 °C to +60 °C. |
Flammability: | UL94 HB. |
Protection: | IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C). |
Finish: | RAL 7035. |
Delivery: | Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide. |
Feature: | ABS terminal box, available in a wide range of sizes, with a high IP 66, 67 protection degree. |
Advantage: | Customers can choose terminal boxes that meet their size requirements, off the shelf. The installed components inside the terminal box will be safe and secure due to the high protection degree. |
Benefit: | Customers can receive terminal boxes with a short delivery time, that match their size requirements. This will also remove any extra costs due to oversizing. Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box. |
Comment: | The mounting plate, DMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box. |
Title: | Size: | Type: |
---|---|---|
DABP081606GE DABP081606GE EN_DABP050504GE.pdf | 431 Kbytes | |
DABP081606GE DABP081606GE AFS08083_Document-(PDF)3.pdf | 514 Kbytes | |
Download general catalog |
