EHG030 nVent HOFFMAN Heater 30W EHG030

Description:

Large heater to be fixed preferably in vertical position to prevent condensation. Mounting clip for 35 mm DIN rail (EN60715).

Heating element:

PTC resistor, self regulating and temperature limiting.

Material:

Plastic, and anodised aluminium profile.

Operating temperature:

-40 °C to +70 °C. The heating capacity is for ambient temperature 20 °C.

Connection:

Plug terminal connection (2 × 0.5-2.5 mm²), available on request with connecting cable (500 mm).

Protection:

IP 20 supplied with terminals. IP 44 on request (supplied with cable).

Approvals:

CE, EAC, cULus_UL Listed.

Pack quantity:

1 piece.

Feature:

Anti-condensation heater, available in a wide range of heating capacities and sizes.

Advantage:

The heater is available in different capacities from 15-150 watts. The heater can be installed in tight spaces, if required or meet the customer's higher heating requirements if space is not an issue.

Benefit:

When installed, water condensation will be avoided especially in situations when the ambient temperature dramatically drops. The wide range in heating capabilities, allows the customer to choose the heater which meets their requirements which avoids over sizing and in turn reduces energy costs.

Comment:

A thermostat with a normally closed contact, ETR or EFR, is recommended in order to control the heater.
