DPCP162412GE nVent HOFFMAN Caja para bornas, 160x240x121, sin MP, policarbonato, IP66

Descripción:

Caja en policarbonato, libre de halógenos, apta para uso exterior. Alta resistencia a los rayos UV. Autoextinguible.

Material:

Policarbonato.

Junta:

Junta de poliuretano integrado en la tapa de la caja.

Resistencia a la temperatura:

-40 °C a +80 °C.

Inflamabilidad:

UL746C 5V.

Protección:

66, 67 IK 08 (-25 °C … +35 °C).

Acabado:

RAL 7035.

Certificaciones:

CE, GOST. Para certificación cULus_UL Listed, contactar con nuestro departamento comercial.

Suministro:

Base de la caja, tapa, tornillos de la tapa en acero inoxidable, tornillos de montaje y embellecedores de poliamida.

Feature:

Polycarbonate terminal box, available in a wide range of sizes, with a high IP 66, 67 protection degree.

Advantage:

Customers can choose terminal boxes that meet their size requirements, off the shelf. The installed components inside the terminal box will be safe and secure due to the high protection degree and resistance to UV radiation.

Benefit:

Customers can receive terminal boxes with a short delivery time, that match their size requirements which can be installed in both indoor and outdoor environments, even in locations where there is direct sunlight. This will also remove any extra costs due to oversizing. Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box.

Comment:

The mounting plate, DMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box.
