Ethernet cables and accessories
EtherCAT patch cables, improved shield
Shape | Connector 1 | Connector 2 | Material | Cable | Color | Length in cm | Order code |
|---|
20 | 30 | 50 | 100 | 150 | 200 | 300 | 500 | 750 | 1000 | 1500 | 2000 |
|---|
| M12 straight | M12 straight | PVC | AWG22, 2 pairs | Black | – | – | ⬛ | ⬛ | – | ⬛ | ⬛ | ⬛ | – | ⬛ | – | – | XS5W-T421-[.]M2-SS |
| M12 straight | RJ45 | PVC | AWG22, 2 pairs | Black | – | – | ⬛ | ⬛ | – | ⬛ | ⬛ | ⬛ | – | ⬛ | – | – | XS5W-T421-[.]MC-SS |
Note: For [.] fill in the 1-character length code.
Ethernet patch cables, standard RJ45 connectors
Shape | Connector 1 | Connector 2 | Material | Cable | Color | Length in cm | Order code |
|---|
20 | 30 | 50 | 100 | 150 | 200 | 300 | 500 | 750 | 1000 | 1500 | 2000 |
|---|
| RJ45 std. | RJ45 std. | LSZH | Cat6a S/FTP 4 pairs | Blue | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | XS6W-6LSZH8SS[...]CM-B |
| RJ45 std. | RJ45 std. | LSZH | Cat6a S/FTP 4 pairs | Yellow | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | XS6W-6LSZH8SS[...]CM-Y |
| RJ45 std. | RJ45 std. | LSZH | Cat6a S/FTP 4 pairs | Green | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | XS6W-6LSZH8SS[...]CM-G |
| RJ45 std. | RJ45 std. | PUR | Cat5e S/FTP 4 pairs | Green | – | – | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | ⬛ | XS6W-5PUR8SS[...]CM-G |
Note: For [...] fill in the length in cm.
Ethernet patch cables, RJ45/M12 connectors
Shape | Connector 1 | Connector 2 | Material | Cable | Color | Length in cm | Order code |
|---|
30 | 50 | 100 | 200 | 300 | 500 | 1000 | 1500 |
|---|
| RJ45 | RJ45 | PVC | Cat5e Shielded Quad | Light Blue | A | B | C | D | E | G | J | K | XS5W-T421-[.]MD-K |
| M12 straight | M12 straight | PVC | Cat5e Shielded Quad | Light Blue | – | B | C | D | E | G | J | K | XS5W-T421-[.]M2-K |
| M12 straight | RJ45 | PVC | Cat5e Shielded Quad | Light Blue | A | B | C | D | E | G | J | K | XS5W-T421-[.]MC-K |
| M12 angled | M12 angled | PVC | Cat5e Shielded Quad | Light Blue | – | B | C | D | E | G | J | K | XS5W-T422-[.]M2-K |
| M12 angled | RJ45 | PVC | Cat5e Shielded Quad | Light Blue | A | B | C | D | E | G | J | K | XS5W-T422-[.]MC-K |
Note: For [.] fill in the 1-character length code.
Specifications
Item | XS6W-6LSZH8SS_CM-_ | XS6W-5PUR8SS_CM-G |
|---|
Rated current | 1 A (at 50°C) |
Withstand voltage | 1,000 VDC for 60 s (leakage current: 1 mA max.) |
Ambient operating temperature | −20 to 60°C | −40 to 85°C |
Ambient storage temperature | −20 to 60°C | −40 to 85°C |
Ambient installation temperature | 0 to 50°C | −10 to 60°C |
Protective structure | IP20 | IP20 |
Accessories
Ethernet cables and accessories
Accessories
Type | Connector | Specification | Color | Length | Order code |
|---|
Ethernet installation cable | none | CAT 5, SF/UTP, 4 × 2 × AWG 24/1
(solid core), Polyurethane (PUR) | Green | 100 m | WM IE-5IC4x2xAWG24/1-PUR |
Ethernet installation cable | none | CAT 5, SF/UTP, 4 × 2 × AWG 26/7
(stranded core), Polyurethane (PUR) | 100 m | WM IE-5CC4x2xAWG26/7-PUR |
Ethernet socket | RJ45 socket | DIN-rail mount socket to terminate
installation cable in the cabinet | Grey | 60 × 17.5 × 67 mm | WM IE-TO-RJ45-FJ-B |
Ethernet field-mount plugs | Metal RJ45 | for AWG22 to AWG26 | Chrome | 52 mm | WM IE-PS-RJ45-FH-BK |
Ethernet field-mount plugs | Plastic RJ45 | for AWG22 to AWG24 | Black | 52 mm | XS6G-T421-1 |
Industrial switching hubs
Shape | Functions | Ports | Failure detection | Power supply voltage | Order code |
|---|
| Quality of Service (QoS): EtherNet/IP control data priority Failure detection: Broadcast storm and LSI error detection
10/100BASE-TX, Auto-negotiation | 3 | – | 24.0 VDC±5% | W4S1-03B |
| 5 | W4S1-05B |
⬛ | W4S1-05C |
EtherCAT junction slave
Shape | Functions | Ports | Power supply voltage | Order code |
|---|
| Creation of star- and tree topologies
in EtherCAT networks. Distributed Clock (DC) is supported. | 3 | 20.4 to 28.8 VDC (24 VDC –15% to 20%) | GX-JC03 |
| 6 | GX-JC06 |
