CEN-60-36 CEN6036 MEANWELL Eingang: 90-295 AC / 127-417 DC, Ausgabe: 1, V1: 42, A1: 1,7 Vergrößern
Die Bilder sind nur orientativ. Bitte prüfen Sie das Artikelstammdatenblatt.

CEN-60-36 CEN6036 MEANWELL Eingang: 90-295 AC / 127-417 DC, Ausgabe: 1, V1: 42, A1: 1,7

CEN-60-36

CEN6036

MEANWELL

Verfügbar

Schiff am heute

Eingang: 90-295 AC / 127-417 DC, Ausgabe: 1, V1: 42, A1: 1,7

Mehr Infos


Spannungsversorgungen

LED-Treiber

CEN

* Neues Produkt in der Originalverpackung mit allen Garantien und Zertifizierungen von MEANWELL

MengePreis
1+$45.86
7+$41.66
13+$40.76
19+$40.28
25+$39.99
*Dieser Preis ist pro Einheit und ist der Nettowert (ohne Steuern, falls zutreffend).

Wie es funktioniert

Wie funktioniert das?

1 Fügen Sie die Produkte Ihrer Wahl in den Warenkorb
2 Geben Sie Ihre Kontaktdaten und senden Sie Ihre Anfrage
3 Sie werden per E-Mail mit unseren Preisvorschläge mitzuteilen
4 Beenden Sie einfach Ihre Bestellung und Sie erhalten die Produkte

Es gibt verschiedene Möglichkeiten die Zahlung abzuwickeln
- Kreditkarte
- Banküberweisung
- PayPal


Verwandte Produkte

Mehr Infos



60W Single Output LED Power SupplyCEN-60series 60W Single Output LED Power SupplyCEN-60series
60W Single Output LED Power SupplyCEN-60series Features : Features :
Features : UniversalAC input / Full range (up to 295VAC) UniversalAC input / Full range (up to 295VAC)
UniversalAC input / Full range (up to 295VAC) Protections: Short circuit / Over current/ Over voltage/ Over temperature Protections: Short circuit / Over current/ Over voltage/ Over temperature
Protections: Short circuit / Over current/ Over voltage/ Over temperature Output voltageand constant currentlevel adjustable Output voltageand constant currentlevel adjustable
Output voltageand constant currentlevel adjustable Built-in active PFC function Built-in active PFC function
Built-in active PFC function IP66 design for indoor or outdoorinstallations IP66 design for indoor or outdoorinstallations
IP66 design for indoor or outdoorinstallations Class 2 power unit Class 2 power unit
Class 2 power unit Cooling by free air convection Cooling by free air convection
Cooling by free air convection 100% full load burn-in test 100% full load burn-in test
100% full load burn-in test High reliability High reliability
High reliability Suitable for LED lighting and moving sign applications Suitable for LED lighting and moving sign applications
Suitable for LED lighting and moving sign applications Compliance to worldwide safetyregulations for lighting Compliance to worldwide safetyregulations for lighting
Compliance to worldwide safetyregulations for lighting Suitable for dry / damp/ wet locations Suitable for dry / damp/ wet locations
Suitable for dry / damp/ wet locations 3 years warranty 3 years warranty
3 years warranty SPECIFICATION SPECIFICATION
SPECIFICATIONF110MM SELV F110MM SELV
F110MM SELVIP66.. IP66..
IP66.. MODEL MODEL
MODEL DC VOLTAGE DC VOLTAGE
DC VOLTAGE CEN-60-12CEN-60-15 CEN-60-12CEN-60-15
CEN-60-12CEN-60-15 12V 15V 12V 15V
12V 15V CEN-60-20CEN-60-24CEN-60-30CEN-60-36 CEN-60-20CEN-60-24CEN-60-30CEN-60-36
CEN-60-20CEN-60-24CEN-60-30CEN-60-36 20V 24V 30V 36V 20V 24V 30V 36V
20V 24V 30V 36V CEN-60-42 CEN-60-42
CEN-60-42 42V 42V
42V CEN-60-48 CEN-60-48
CEN-60-48 48V 48V
48V CEN-60-54 CEN-60-54
CEN-60-54 54V 54V
54V CONSTANT CURRENT REGION Note.5 9 ~ 12V 11.25 ~ 15V CONSTANT CURRENT REGION Note.5 9 ~ 12V 11.25 ~ 15V
CONSTANT CURRENT REGION Note.5 9 ~ 12V 11.25 ~ 15V 15 ~ 20V 18 ~ 24V 22.5 ~ 30V27 ~ 36V 15 ~ 20V 18 ~ 24V 22.5 ~ 30V27 ~ 36V
15 ~ 20V 18 ~ 24V 22.5 ~ 30V27 ~ 36V 31.5 ~ 42V 31.5 ~ 42V
31.5 ~ 42V 36 ~ 48V 36 ~ 48V
36 ~ 48V 40.5 ~ 54V 40.5 ~ 54V
40.5 ~ 54V RATED CURRENT CURRENT RANGE RATED POWER RATED CURRENT CURRENT RANGE RATED POWER
RATED CURRENT CURRENT RANGE RATED POWER 5A4A 5A4A
5A4A 0 ~ 5A 0 ~ 4A 0 ~ 5A 0 ~ 4A
0 ~ 5A 0 ~ 4A 60W60W 60W60W
60W60W 3A 2.5A2A 1.7A 3A 2.5A2A 1.7A
3A 2.5A2A 1.7A 0 ~ 3A 0 ~ 2.5A0 ~ 2A 0 ~ 1.7A 0 ~ 3A 0 ~ 2.5A0 ~ 2A 0 ~ 1.7A
0 ~ 3A 0 ~ 2.5A0 ~ 2A 0 ~ 1.7A 60W60W60W61.2W 60W60W60W61.2W
60W60W60W61.2W 1.45A 1.45A
1.45A 0 ~ 1.45A 0 ~ 1.45A
0 ~ 1.45A 60.9W 60.9W
60.9W 1.3A 1.3A
1.3A 0 ~ 1.3A 0 ~ 1.3A
0 ~ 1.3A 62.4W 62.4W
62.4W 1.15A 1.15A
1.15A 0 ~ 1.15A 0 ~ 1.15A
0 ~ 1.15A 62.1W 62.1W
62.1WOUTPUT OUTPUT
OUTPUT RIPPLE & NOISE (max.) Note.22Vp-p2.4Vp-p VOLTAGE ADJ. RANGE (SVR1)10.8 ~ 13.5V 13.5 ~ 17V CURRENT ADJ. RANGE(SVR2)3.75 ~ 5A3 ~ 4A VOLTAGE TOLERANCE Note.310% RIPPLE & NOISE (max.) Note.22Vp-p2.4Vp-p VOLTAGE ADJ. RANGE (SVR1)10.8 ~ 13.5V 13.5 ~ 17V CURRENT ADJ. RANGE(SVR2)3.75 ~ 5A3 ~ 4A VOLTAGE TOLERANCE Note.310%
RIPPLE & NOISE (max.) Note.22Vp-p2.4Vp-p VOLTAGE ADJ. RANGE (SVR1)10.8 ~ 13.5V 13.5 ~ 17V CURRENT ADJ. RANGE(SVR2)3.75 ~ 5A3 ~ 4A VOLTAGE TOLERANCE Note.310% 1.8Vp-p 2.4Vp-p 3Vp-p3.6Vp-p 1.8Vp-p 2.4Vp-p 3Vp-p3.6Vp-p
1.8Vp-p 2.4Vp-p 3Vp-p3.6Vp-p 17 ~ 22V 22 ~ 27V 27 ~ 33V 33 ~ 40V 17 ~ 22V 22 ~ 27V 27 ~ 33V 33 ~ 40V
17 ~ 22V 22 ~ 27V 27 ~ 33V 33 ~ 40V 2.3 ~ 3A1.9 ~ 2.5A1.5 ~ 2A1.3 ~ 1.7A 2.3 ~ 3A1.9 ~ 2.5A1.5 ~ 2A1.3 ~ 1.7A
2.3 ~ 3A1.9 ~ 2.5A1.5 ~ 2A1.3 ~ 1.7A 4Vp-p 4Vp-p
4Vp-p 37 ~ 46V 37 ~ 46V
37 ~ 46V 1.1 ~ 1.45A 1.1 ~ 1.45A
1.1 ~ 1.45A 4.6Vp-p 4.6Vp-p
4.6Vp-p 43 ~ 53V 43 ~ 53V
43 ~ 53V 1 ~ 1.3A 1 ~ 1.3A
1 ~ 1.3A 5Vp-p 5Vp-p
5Vp-p 49 ~ 58V 49 ~ 58V
49 ~ 58V 0.9 ~ 1.15A 0.9 ~ 1.15A
0.9 ~ 1.15A LINE REGULATION LOAD REGULATION SETUP TIME LINE REGULATION LOAD REGULATION SETUP TIME
LINE REGULATION LOAD REGULATION SETUP TIME 3.0% 3.0%
3.0% 5.0% 5.0%
5.0% 500ms / 230VAC1200ms / 115VAC at full load 500ms / 230VAC1200ms / 115VAC at full load
500ms / 230VAC1200ms / 115VAC at full load VOLTAGE RANGE Note.4 90 ~ 295VAC127 ~ 417VDC VOLTAGE RANGE Note.4 90 ~ 295VAC127 ~ 417VDC
VOLTAGE RANGE Note.4 90 ~ 295VAC127 ~ 417VDC FREQUENCY RANGE POWER FACTOR (Typ.) FREQUENCY RANGE POWER FACTOR (Typ.)
FREQUENCY RANGE POWER FACTOR (Typ.) TOTAL HARMONIC DISTORTION TOTAL HARMONIC DISTORTION
TOTAL HARMONIC DISTORTION 47 ~ 63Hz 47 ~ 63Hz
47 ~ 63Hz PF>0.97/115VAC, PF>0.95/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve) THD< 20% when output loading75% at 115VAC/230VAC input and output loading80% at 277VAC input PF>0.97/115VAC, PF>0.95/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve) THD< 20% when output loading75% at 115VAC/230VAC input and output loading80% at 277VAC input
PF>0.97/115VAC, PF>0.95/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve) THD< 20% when output loading75% at 115VAC/230VAC input and output loading80% at 277VAC input INPUT INPUT
INPUT EFFICIENCY (Typ.) EFFICIENCY (Typ.)
EFFICIENCY (Typ.) 86% 87% 86% 87%
86% 87% 88% 89% 90% 90% 88% 89% 90% 90%
88% 89% 90% 90% 90% 90%
90% 91% 91%
91% 91% 91%
91% AC CURRENT (Typ.) INRUSH CURRENT (Typ.) MAX. No. of PSUs on 16A AC CURRENT (Typ.) INRUSH CURRENT (Typ.) MAX. No. of PSUs on 16A
AC CURRENT (Typ.) INRUSH CURRENT (Typ.) MAX. No. of PSUs on 16A CIRCUIT BREAKER CIRCUIT BREAKER
CIRCUIT BREAKER LEAKAGE CURRENT OVER CURRENT LEAKAGE CURRENT OVER CURRENT
LEAKAGE CURRENT OVER CURRENT SHORT CIRCUIT SHORT CIRCUIT
SHORT CIRCUIT 0.8A/115VAC0.4A/230VAC 0.3A/277VAC 0.8A/115VAC0.4A/230VAC 0.3A/277VAC
0.8A/115VAC0.4A/230VAC 0.3A/277VAC COLD START 45A(twidth=85s measured at 50% Ipeak) at 230VAC COLD START 45A(twidth=85s measured at 50% Ipeak) at 230VAC
COLD START 45A(twidth=85s measured at 50% Ipeak) at 230VAC32 units (circuit breaker of type B) / 32 units (circuit breaker of type C) at 230VAC 32 units (circuit breaker of type B) / 32 units (circuit breaker of type C) at 230VAC
32 units (circuit breaker of type B) / 32 units (circuit breaker of type C) at 230VAC<0.75mA / 240VAC <0.75mA / 240VAC
<0.75mA / 240VAC 95 ~ 110% 95 ~ 110%
95 ~ 110% Protection type : Constant current limiting, recovers automatically after fault condition is removed Protection type : Constant current limiting, recovers automatically after fault condition is removed
Protection type : Constant current limiting, recovers automatically after fault condition is removed Hiccup mode, recovers automatically after fault condition is removed Hiccup mode, recovers automatically after fault condition is removed
Hiccup mode, recovers automatically after fault condition is removed PROTECTION PROTECTION
PROTECTION 14.5 ~ 17V17.5 ~ 21V 14.5 ~ 17V17.5 ~ 21V
14.5 ~ 17V17.5 ~ 21V 22.8 ~ 26V28 ~ 34V 34 ~ 38V 41 ~ 46V 22.8 ~ 26V28 ~ 34V 34 ~ 38V 41 ~ 46V
22.8 ~ 26V28 ~ 34V 34 ~ 38V 41 ~ 46V 47 ~ 52V 47 ~ 52V
47 ~ 52V 54 ~ 60V 54 ~ 60V
54 ~ 60V 59 ~ 65V 59 ~ 65V
59 ~ 65VENVIRONMENT ENVIRONMENT
ENVIRONMENT SAFETY & EMC SAFETY & EMC
SAFETY & EMCOTHERS OTHERS
OTHERS OVER VOLTAGE OVER VOLTAGE
OVER VOLTAGEOVER TEMPERATURE WORKING TEMP. WORKING HUMIDITY OVER TEMPERATURE WORKING TEMP. WORKING HUMIDITY
OVER TEMPERATURE WORKING TEMP. WORKING HUMIDITY STORAGE TEMP., HUMIDITY STORAGE TEMP., HUMIDITY
STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION TEMP. COEFFICIENT VIBRATION
TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION SAFETY STANDARDS WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION
SAFETY STANDARDS WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION EMC IMMUNITY MTBF DIMENSION EMC IMMUNITY MTBF DIMENSION
EMC IMMUNITY MTBF DIMENSION PACKING PACKING
PACKING Protection type : Shut down o/p voltage, re-power on to recover Protection type : Shut down o/p voltage, re-power on to recover
Protection type : Shut down o/p voltage, re-power on to recover Shut down o/p voltage, re-power on to recover Shut down o/p voltage, re-power on to recover
Shut down o/p voltage, re-power on to recover -30 ~ +70C (Refer to "Derating Curve") -30 ~ +70C (Refer to "Derating Curve")
-30 ~ +70C (Refer to "Derating Curve") 20 ~ 95% RH non-condensing 20 ~ 95% RH non-condensing
20 ~ 95% RH non-condensing -40 ~ +80C, 10 ~ 95% RH -40 ~ +80C, 10 ~ 95% RH
-40 ~ +80C, 10 ~ 95% RH 0.03%/C (0 ~ 50C) 0.03%/C (0 ~ 50C)
0.03%/C (0 ~ 50C) 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes UL879, UL8750, CSA C22.2 No. 207-M89, CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, IP66, J61347-1, J61347-2-13 approved UL879, UL8750, CSA C22.2 No. 207-M89, CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, IP66, J61347-1, J61347-2-13 approved
UL879, UL8750, CSA C22.2 No. 207-M89, CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, IP66, J61347-1, J61347-2-13 approved I/P-O/P:3.75KVAC I/P-FG:2KVACO/P-FG:0.5KVAC I/P-O/P:3.75KVAC I/P-FG:2KVACO/P-FG:0.5KVAC
I/P-O/P:3.75KVAC I/P-FG:2KVACO/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25C/ 70% RH I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25C/ 70% RH
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25C/ 70% RH Compliance to EN55015, EN61000-3-2 Class C (75% load) ; EN61000-3-3 Compliance to EN55015, EN61000-3-2 Class C (75% load) ; EN61000-3-3
Compliance to EN55015, EN61000-3-2 Class C (75% load) ; EN61000-3-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547, light industry level (surge 4KV), criteria B Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547, light industry level (surge 4KV), criteria B
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547, light industry level (surge 4KV), criteria B 523.4Khrs min.MIL-HDBK-217F (25C) 523.4Khrs min.MIL-HDBK-217F (25C)
523.4Khrs min.MIL-HDBK-217F (25C) 185*62.5*40.5mm (L*W*H) 185*62.5*40.5mm (L*W*H)
185*62.5*40.5mm (L*W*H) 0.6Kg;24pcs/15.4Kg/1.29CUFT 0.6Kg;24pcs/15.4Kg/1.29CUFT
0.6Kg;24pcs/15.4Kg/1.29CUFTNOTE NOTE
NOTE 1. All parameters NOT speciallymentioned are measured at 230VAC input, ratedload and 25C of ambient temperature. 1. All parameters NOT speciallymentioned are measured at 230VAC input, ratedload and 25C of ambient temperature.
1. All parameters NOT speciallymentioned are measured at 230VAC input, ratedload and 25C of ambient temperature. 2. Ripple & noiseare measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 2. Ripple & noiseare measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
2. Ripple & noiseare measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes setup tolerance, line regulation and load regulation. 3. Tolerance : includes setup tolerance, line regulation and load regulation.
3. Tolerance : includes setup tolerance, line regulation and load regulation. 4. Deratingmay be needed underlow input voltage.Please checkthe static characteristics for more details. 4. Deratingmay be needed underlow input voltage.Please checkthe static characteristics for more details.
4. Deratingmay be needed underlow input voltage.Please checkthe static characteristics for more details. 5. Please refer to "DRIVING METHODS OF LED MODULE". 5. Please refer to "DRIVING METHODS OF LED MODULE".
5. Please refer to "DRIVING METHODS OF LED MODULE". 6. The powersupply is considered as a component that will be operated in combination with final equipment. SinceEMC performance will be affected by the complete installation,the final equipment manufacturers must re-qualify EMC Directive on the complete installationagain. 6. The powersupply is considered as a component that will be operated in combination with final equipment. SinceEMC performance will be affected by the complete installation,the final equipment manufacturers must re-qualify EMC Directive on the complete installationagain.
6. The powersupply is considered as a component that will be operated in combination with final equipment. SinceEMC performance will be affected by the complete installation,the final equipment manufacturers must re-qualify EMC Directive on the complete installationagain. 7. Direct connecting to LEDs is suggested, but is not suitable for using additionaldrivers. 7. Direct connecting to LEDs is suggested, but is not suitable for using additionaldrivers.
7. Direct connecting to LEDs is suggested, but is not suitable for using additionaldrivers. 8. To fulfill requirements of the latestErP regulation for lighting fixtures, this LED powersupply canonly be used behinda switch without permanently connected to the mains. 8. To fulfill requirements of the latestErP regulation for lighting fixtures, this LED powersupply canonly be used behinda switch without permanently connected to the mains.
8. To fulfill requirements of the latestErP regulation for lighting fixtures, this LED powersupply canonly be used behinda switch without permanently connected to the mains. File Name:CEN-60-SPEC2015-05-28 File Name:CEN-60-SPEC2015-05-28
File Name:CEN-60-SPEC2015-05-28

Datasheet - PDF

Title:Language:Size:Type:
pdf-Eingang: 90-295 AC / 127-417 DC, Ausgabe: 1, V1: 42, A1: 1,7 - MEANWELL - CEN-60-36 - CEN6036English158 Kbytespdf-Eingang: 90-295 AC / 127-417 DC, Ausgabe: 1, V1: 42, A1: 1,7 - MEANWELL - CEN-60-36 - CEN6036
